More Projects

SSRP

Contents:
Subjects:

I built a single-board version of David Carr's Simple Software Radio Peripheral.  This is a USB-connected ADC that can be used for software radio work.

SSRP board Read more »

FPGA Platform Game

Contents:
Subjects:

This is an old Nintendo-style side-scrolling game written entirely in VHDL. There is no microprocessor. The hardware consists of: Read more »

Software-Defined Radio

Contents:
Subjects:

This board downconverts and digitizes the FM broadcast band. It connects to the Digilent S3E-1600 board which selects a channel and sends the IF over Ethernet to a computer which demodulates the audio.

The sample clock is produced by a CY22150 clock synthesizer connected to J4 on the S3E-1600 board. Read more »

USB JTAG Adapter

Contents:
Subjects:

This is basically a clone of the Amontec JTAGkey. It uses the FT2232C (superseded by the FT2232D) and requires no firmware. There is an EEPROM on the board to store the USB product and vendor IDs. It will work with 1.8V-5.0V targets.

Assembled Adapter Read more »

Accelerometer

Contents:

This is a device a built a few years ago to measure and record acceleration in 3D. It records acceleration from three perpendicular MEMS accelerometers at 28.125 samples per second (that rate was convenient, trust me) and stores it in serial flash. Read more »

Reflow Toaster

Contents:
Subjects:

This is a toaster modified to work as a reflow oven. The toaster itself is largely unchanged except that its electrical system has been reduced to a few wires. The heater elements are now controlled by an ATmega16 microcontroller via a solid state relay. A thermocouple measures the temperature of the board. A MAX6675 reports the temperature of the thermocouple to the microcontroller. Read more »

Subscribe to RSS - More Projects
